Find Big Brake Kits for your Mustang

Wilwood SX6R WCCB Carbon Ceramic Front Big Brake Kit; Red Calipers (15-23 Mustang)Find parts that fit my vehicle

Item 407320
Product Image
Wilwood SX6R WCCB Carbon Ceramic Front Big Brake Kit; Red Calipers (15-23 Mustang)
Verify parts fit and get product recommendations.
Mustang Sales Techs: Connect Now M-F 8:30A-11P, Sat-Sun 8:30A-9P
Call now 1-877-887-1105 Chat Now
$0.00
Want $10? Write one of the first 5 reviews 4.7 Wilwood Brakes product ratings
Our Price

$9,121.83 kit

Out of Stock

to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.

Will this fit your Vehicle?

Select a different vehicle Help?
Update or Change Vehicle
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Loading Indicator

      Product Information

      Features, Description, Q&A, Specs & Installation

      Features & Specs

      • Superior Braking Performance
      • Ideal for Street and Tracking Applications
      • SX6R 6-Piston Aluminum Calipers
      • Durable Red Powder Coat Finish
      • Two-Piece 15-Inch Vane Vented Brake Rotors
      • Carbon Ceramic Construction with Aluminum Rotor Hats
      • Bolt-On Upgrade - Minor Modifications Required to Front Spindle
      • Compatible with ABS and OE Master Cylinder Output
      • Front Brake Kit
      • Fits 2015-2023 Ford Mustang Models

      Description

      Exceptional Stopping Power. The factory brakes are fine for those who use their Mustang as a daily driver, but if you find yourself carving corners at the track you want to know that your brakes can handle the extra heat generated. So, upgrade your Mustang to a Wilwood SX6R WCCB Carbon-Ceramic Front Big Brake Kit. By providing enough capability to shorten stopping distances, this kit is consequently ideal for extreme duty and race vehicles like your beloved Mustang.

      SX6R Brake Calipers. Wilwood's SX6R radial mount six piston brake calipers are forged from aluminum for lightweight and superior strength. These SX6R calipers feature stainless steel pistons with high-temp internal bore seals for dependable braking performance. Wilwood completes their brake calipers in a durable gloss red powder coated finish for aggressive good looks and long lasting corrosion protection.

      WCCB Carbon-Ceramic Rotors. The included plain face 15-inch, vented WCCB rotors are made from a proprietary blend ceramic matrix composite material commonly known as Carbon-Ceramic. WCCB rotors offer higher thermal conductivity and heat capacity in excess of conventional iron or titanium rotors of similar or even greater size. WCCB rotors have been developed to withstand extreme temperatures with the highest possible degree of resistance against distortion, warping, cracking and wear.

      Complete Kit. Wilwood's SX6R Front Big Brake Kit includes SX6R 6-Piston calipers, high performance PCM brake pads, two piece 15-inch WCCD Carbon-Ceramic Rotors, braided stainless steel brake lines and all the hardware required for a straight forward bolt-on installation.

      Bolt-On Upgrade. Wilwood designed their SX6R Big Brake Kit to be a direct replacement of your stock Mustang calipers and rotors with the company’s exclusive Bobbin mounting system. Please note that minor modifications to the front spindle are required for installation. Expect to spend up to 4 hours to complete the install.

      Application. This Wilwood SX6R WCCB Carbon-Ceramic Front Big Brake Kit with Red Calipers is designed for use on 2015-2023 Ford Mustang models. Requires the use of 19-inch or larger rims for proper clearance.

      Fitment:

      Wilwood 140-15356-CSICR

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      What's in the Box

      • (1) Driver Side SX6R 6-Piston Caliper
      • (1) Passenger Side SX6R 6-Piston Caliper
      • (2) 15-Inch 2-Piece WCCB Carbon-Ceramic Rotors
      • PCM Brake Pads
      • Stainless Steel Brake Lines
      • Mounting Brackets
      • Installation Hardware
