How to Install RTR Side Rocker Splitters (15-17 All) on your Ford Mustang

Step 1: Remove two torx screws and plastic retaining clip holding the plastic splash shield. Remove shield.

Step 2: Remove the 8 clips securing the plastic radiator cover to the support and remove it from the vehicle.

Step 3: Prep the tape mounting surface with the supplied alcohol swabs and adhesion promoter.

Step 4: Peel back the red plastic film to expose the double sided tape.

**Note: only peel off enough to get it started. Install the Rocker splitter using the factory retaining clips. Once the splitters are where you want them, peel the red film off and apply firm even pressure.

Step 5: Locate and remove the two plastic push clips that fasten the rear bumper.

Step 6: Clean the area the tape will mount to using the supplied alcohol swab and adhesion promoter.

Step 7: Secure with factory plastic push clips. **Note: push clips will be tight and will require more pressure to seat the clip.

Step 8: Peel the plastic backing film, and firmly press the rear splitter to the bumper.
